Fly Sky FS-CPD02 Photoinduction Speed Collection Module For iA6B iA10

PRODUCT INFORMATION:

• Flysky FS-CPD02 Photoinduction Speed Collection Module for iA6B iA10

  Specifications:
  • Model type: car/boat/helicopter/ airplane/ glider
  • Monitor range of speed: 0-60000RPM
  • Weight: 6.8g
  • Power: 4.0-6.5V/DC
  • Size: 31*15*8.5mm
  • Color: Black
  • Optical distance: 5-30mm
  • Compatible Receiver: iA4B(directly), iA6B(directly), iA10(need conversion cable)

  RPM Telemetry (Optical) Module Setup Operation:
  • Connect one end of the standard 3 PIN plug to the "out" port of the speed telemetry module and the other end to the "in" port of the receiver or the previous sensors “in” port.
  • Affix the sensor and the reflection decals on the flat surface of the side of any rotating part. Keep decals flat and perpendicular to the sensor. Maintain sufficient safety distance between the sensor and the decals to avoid any damage.
  • Switch on the transmitter and the receiver. “Motor speed 2: 0RPM” will be displayed on the main screen. The speed displayed will follow the speed of the rotating part monitored by the rotation speed sensor, indicating a successful installation

  Package Includes:

  • FS-CPD02 Module x1
